1 AWG 4 Core 400/26 Stranded Flexible BC PUR Jacket Power Control Cable - Ideal for Industrial Machinery, Automation Systems & Heavy-Duty Electrical Applications

Product Description

1 AWG 4 Cores 400/26 Stranded FLEX-P BC PUR Jacket Power And Control Cable 1600104

Allowable Ampacity for 1 AWG 4 Cores 400/26 Stranded FLEX-P BC PUR Jacket Power And Control Cable 1600104: 100 Amps

Also Known as:

Mueller Cable, FLEX-P Cable, Flexible Cable, Multi-Conductor Cable, Flexible Control Cable, Non-Shielded Cable, 300/500V Cable, 1600104 Cable

Description:

FLEX-P is a polyurethane, flexible, oil-resistant, multi-conductor power and control cable designed for use in all electrical equipment in dry, damp, and wet conditions. For use in flexible or stationary applications under high mechanical stress with free movement without any tensile stress, loads, or forced movements. Common applications include connections and control to CNC machines, machine tools, control systems, assembly lines, control panel to machine connections, grinding machines, and bottling equipment. Found in plant engineering, paint shops, power stations, and refrigeration plants. The rugged polyurethane outer jacket ensures excellent chemical, coolant, abrasion, and tear resistance making FLEX-P suitable for applications in contact with mineral oils and chemicals. Outdoor installation is not permitted.

Construction:

• Fine bare copper strands
• Strands to VDE-0295 Class-5, IEC 60228 Cl-5
• Special PVC core insulation
• Color code VDE-0293 - black & numbered
• The ground wire in the outer layer
• PUR outer jacket - gray (RAL 7001)
• “OZ” denotes no ground wire
• Extremely oil & chemical resistant

Technical:

• Working voltage: 300/500 volts
• Testing voltage: 3000 volts
• Flexing bending radius: 12,5 x Ø
• Static bending radius: 5 x Ø
• Flexing temp: -5º C to +70º C
• Static temp: -40º C to +80º C
• Flame retardant: IEC 60332.1
• Insulation resistance: 20 MΩ x km

Approvals:

• VDE-0245, 0250, 0282, 0285
• CE Low Voltage Directive 2014/35/EU
• RoHS compliant

Specification:

• Size AWG: 1
• Stranded: 400/26
• Number of Cores: 4
• Nominal OD: 1.531 Inch
• Weight CU: 1288 LBS/MFT
• Weight 1000ft: 1610 LBS/MFT
• Part Number: 1600104
